VGA TO HDMI

HDMI Converter ( VGA TO HDMI )
P/N:HCV0101

INTRODUCTION
This kind of the Converter is a VGA video converter. It converts VGA input into HDMI to allow PC users to show their image not only on the PC’s monitor, but could also on TV, to have a large display.
The conversion is along with the R/L audio. HCV0101 offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments. Every effort has been made to ensure that this product is free of defects. Bridging (HK) Limited cannot be held liable for the use of this hardware or any direct or indirect consequential damages arising from its use.
It is the responsibility of the user of the hardware to check that it is suitable for his/her requirements and that it is installed correctly. All rights reserved. No parts of this manual may be reproduced or transmitted by any form or means electronic or mechanical, including photocopying, recording or by any information storage or retrieval system without the written consent of the publisher.
Bridging (HK) Limited reserves the right to revise any of its hardware and software following its policy to modify and/or improve its products where necessary or desirable. This statement does not affect the legal rights of the user in any way. All third party trademarks and copyrights are recognized.


FEATURES
The series of the HDMI Amplifier Switcher have many features that enable them to perform in a superior manner.
Among those features you will find: Easy to Use: Install in seconds, no need of setting. Conversion: It could convert PC’s VGA video and R/L audio into completeHDMI.
Extra VGA and R/L audio outputs: the outputs could be connected back to PC’s monitor and speakers.
Manual adjusting button: used for position the image precisely under some extreme condition. HDCP compliant.

SPECIFICATIONS
Signal Inputs/Output
Input Video Signal.................................0.5-1.0 volts p-p
Input DDC Signal...................................5 volts p-p (TTL)
Maximum Single Link Range..........................1600X1200, 1080P
Output Video ......................................HDMI + HDCP1.0/1.1
VGA................................................640x480 60Hz 72Hz 75Hz
                                                   800x600 60Hz 72Hz 75Hz
                                                   1024x768 60Hz 70Hz 75Hz
                                                   1280x1024 60Hz
                                                   1600x1200 60Hz
DTV/HDTV...........................................480i/576i/480p/576p/720p/1080i/1080P
Digital Signal I/O.................................HDMI Compliance HDMI 1.3
Operating Frequency................................Up to165Mhz
Video Amplifier Bandwidth..........................1.65Gpbs/165MHz
Resolutions(HDTV) Interlaced(50&60Hz)..............480i,576i,1080i
Progressive(50&60Hz)...............................480p,576p,720p,1080p
Mechanical Size(W-H-D).............................89mmW x 29mmH x 68mmD
Weight(Net)........................................0.68kgs
Warranty Limited Warranty..........................1 Year
Parts and Labor Environmental Operating Temperature............0 ℃ to +70℃
Operating Humidity.................................10% to 85 % RH (no condensation)
Storage Temperature..............................-10℃ to +80℃
Storage Humidity...................................5% to 95 % RH (no condensation)
Power Requirement External Power Supply............5V DC@1A
Regulatory Approvals Converter Unit..................FCC,CE,
Power Supply.........................................CE,FCC
Accessories Adapter AC Power Adapter................US standard, UK standard and so on User Manual


Note: Specifications are subject to change without notice.
